JBL PRX 935 Professional Powered Full-Range Active Speaker
- Brand: JBL
- Product Code:Professional Powered Full-Range Active Speaker
- Availability:In Stock
-
Price: Rp33,700,000
The JBL PRX935 is a professional 2,000-watt peak (1,000W RMS) powered three-way PA loudspeaker featuring a single 15-inch woofer, a 6-inch midrange driver, and a 1.5-inch compression driver. It delivers a max SPL of 136.1 dB, comprehensive dbx DriveRack DSP, and Bluetooth app control.
Acoustic and Power Performance
- Power Output: 2,000 watts peak / 1,000 watts RMS via efficient Class-D amplification.
- Frequency Response: 40 Hz – 20 kHz (-10 dB); 46 Hz – 18 kHz (-3 dB).
- Maximum SPL: 136.1 dB.
- Coverage Pattern: 90° × 50° nominal dispersion via updated Image Control Waveguides.
- Crossover Frequencies: 542 Hz and 2,100 Hz.
Transducers and Hardware
- Low Frequency: 1 × 15-inch ferrite magnet woofer (916G).
- Mid Frequency: 1 × 6-inch ferrite magnet midrange transducer (196H).
- High Frequency: 1 × 1.5-inch poly-annular diaphragm compression driver (2408H-2).
- Enclosure: 18 mm birch plywood cabinet with rugged DuraFlex finish and FEA-flared port design.
- Cooling: Natural convection, fanless quiet operation.
- DSP and Control
- Onboard Processing: dbx DriveRack technology including fixed/live Automatic Feedback Suppression, system limiter, 12-band parametric EQ, and up to 180 ms of speaker delay.
- Display: Onboard full-color LCD screen.
- App Control: Bluetooth Low Energy (BLE) via the JBL Pro Connect App for managing up to 10 systems.
Physical Dimensions and Weight
- Dimensions (H x W x D): 938.5 mm × 446 mm × 434 mm (36.9 in × 17.5 in × 17.1 in)
- Net Weight: 36.6 kg (80.6 lbs)
- Mounting: Single-angle 36 mm pole socket and 8× M10 suspension points.
Tags: JBL
