New ATC designed and built 25mm soft dome HF unit with precision alloy wave guide.
SL spec bass driver with 75mm integral soft dome.
9kg optimised short-coil/long gap motor assembly.
In-house, hand-wound precision flat wire coil.
Flat impedance curve allowing easy load for amplifiers.
Spesification:
Drivers: HF ATC 25mm Neodymium soft dome, Mid/LF ATC 150mm SL
Matched Response: 0.5dB
Frequency Response (-6dB): 54Hz-22kHz
Dispersion: 80 Coherent Horizontal, 10 Coherent Vertical
Sensitivity: 85dB @ 1W @ 1metre
Max SPL: 108dB
Recommended Power Amplifier: 75 to 300 Watts
Nominal Impedance: 8 Ohm
Crossover Frequency: 2.5kHz
Connectors: Binding Posts/4mm Plugs, bi-wire
Cabinet Dimensions (HxWxD): 438x265x300mm (grill adds 28mm to depth)
