KEF R5 Meta Floorstanding Passive Speaker

Compact three-way floorstanding speakers
The slim and elegant R5 Meta is compact, but it is more than capable of delivering highly detailed sound and deep, clean bass. It boasts the 12th generation Uni-Q driver array with MAT and two 5.25” hybrid aluminium bass drivers. It can work as a stereo pair or as surround speakers as part of an ultimate R Series home theatre system.

Performance redefined.
An icon born from The Reference.
Developed for KEF’s flagship The Reference, a suite of the latest technologies has now made its way into the new generation of the R Series. Whether in stereo for music or in a home theatre set up the R Series makes exceptional acoustic performance more accessible. Now with the groundbreaking Metamaterial Absorption Technology, the R Series reveals exquisite detail and incredible insight: truly an experience to savour.

Innovation
R Series: Born from The Reference
Since 1961, KEF’s quest to reproduce immaculate sound has led to many acoustic innovations. The Reference is a case in point. Distilling decades of experience into an acoustic performance that is nothing short of exceptional, it is a design that continually sets the benchmark for loudspeakers and sound reproduction. Now the latest technological innovations have also made their way into the R Series.

Metamaterial Absorption Technology
Absorb 99% of unwanted sound
At the heart of the R Series is Metamaterial Absorption Technology (MAT). MAT is a highly complex maze-like structure that absorbs 99% of the unwanted noise from the rear of the driver, eliminating the resulting distortion and providing purer, more natural sound.




DESIGN
Three-way bass reflex
DRIVE UNITS
Uni-Q Driver Array:
HF: 25 mm (1 in.) vented aluminium dome with MAT
MF: 125 mm (5 in.) aluminium cone
Bass Unit:
LF: 2 x 130 mm (5.25 in.) hybrid aluminium cone
CROSSOVER FREQUENCY
400 Hz, 2.7 kHz
FREQUENCY RANGE (-6dB)
38 Hz - 50 kHz
TYPICAL IN-ROOM BASS RESPONSE (-6dB)
29 Hz
FREQUENCY RESPONSE (±3dB)
52 Hz - 28 kHz
HARMONIC DISTORTION (90dB, 1m)
MAXIMUM OUTPUT
110 dB
AMPLIFIER REQUIREMENTS
15 - 200W
NOMINAL IMPEDANCE
4 Ω (min. 3.2 Ω)
SENSITIVITY (2.83V/1m)
87 dB
WEIGHT *
24.5 kg (54.0 lbs)
DIMENSION (H x W x D) WITH TERMINAL *
1025 x 175 x 344 mm (40.4 x 6.9 x 13.5 in.)
DIMENSION (H x W x D) WITH TERMINAL WITH PLINTH *
1072 x 272 x 344 mm (42.2 x 10.7 x 13.5 in.)
